Performance and features:
QA95-160/250 350 500 800T Billet Shearing Machine, Q42 series of open Shearing Machine, it applies to the metallurgical, mining, construction, automobile manufacturing and other industries. Above  machines after replacement of blade can be used in shearing of  sheet and flat steel, round steel, Square steel, angle steel and other metal materials.The company can also design sepcial specifications for the special-purpose as per customer¡¯s requirement.It can design, manufacture complete sets of equipment of rolling and half-rolling  for small and medium-sized rolling mill .

Technical parameters£º


Model	QA95-160	QA95-250	QA95-300	QA95-400	QA95-500	QA95-600	QA95-800	QA95-1000
Shear stress £¨KN£©	1600	2500	3000	4000	5000	6000	8000	10000
Slider trip £¨mm£©	160	160	100	100	100	100	160	160
Empty trips £¨rpm£©	25	25	25	23	23	23	21	21
Shear number £¨rpm£©	10-25	10-25	10-20	10-20	10-15	10-15	10-15	10-15
Shear width £¨mm£©	450	500	650	800	800	900	900	900
Flywheel speed £¨rpm£©	608	608	596	575	575	575	580	600
Table height £¨mm£©	500	540	600	600	650	650	700	720
Motor Power £¨KW£©	37	45	45	55	55	75	110	132
